G1213-02

SAS 29p

SAS 29 pin, 15u" & 30u"
High Speed Support: SATA 3.0(6Gb/s)&SAS 3.0(12Gb/s)

  • Orientation Vertical
  • PCB Mounting Style SMT
    Housing Material LCP
  • Contact Material Brass
  • Pitch 1.27
  • Housing Color Black
    Data Rates 12Gpbs
  • Size H=8.15mm
Product Drawing

G1213-63

PCIe SAS

PCIe SAS 68 pin, 15u" & 30u"   (SFF 8639)
High Speed Support: SATA 3.0(6Gb/s)&SAS 3.0(12Gb/s)

  • Orientation Vertical
  • PCB Mounting Style SMT
  • Housing Material LCP
  • Contact Material Brass
  • Pitch 1.27
  • Housing Color Black
    Data Rates 24Gpbs
  • Size H=8.15mm
Product Drawing

G1213-8000

mini SAS HD

mini SAS HD vertical 1x1, 15u" & 30u"   (SFF 8643)
High Speed Support: SAS 3.0(12Gb/s)

  • Orientation Vertical
  • PCB Mounting Style Press Fit
    Housing Material LCP
  • Contact Material Brass
  • Pitch 0.75
  • Housing Color Black
    Data Rates 12Gpbs
Product Drawing

G1213-8001

mini SAS HD

mini SAS HD vertical 1x2, 15u" & 30u"   (SFF 8643)
High Speed Support: SAS 3.0(12Gb/s)

  • Orientation Vertical
  • PCB Mounting Style Press Fit
    Housing Material LCP
  • Contact Material Brass
  • Pitch 0.75
  • Housing Color Black
    Data Rates 12Gpbs
Product Drawing

G1213-8100

mini SAS HD

mini SAS HD RA 1x1, 15u" & 30u"   (SFF 8643)
High Speed Support: SAS 3.0(12Gb/s)

  • Orientation Right Angle
  • PCB Mounting Style Press Fit
    Housing Material LCP
  • Contact Material Brass
  • Pitch 0.75
  • Housing Color Black
    Data Rates 12Gpbs
Product Drawing

G1213-8101

mini SAS HD

mini SAS HD RA 1x2, 15u" & 30u"   (SFF 8643)
High Speed Support: SAS 3.0(12Gb/s)

  • Orientation Right Angle
  • PCB Mounting Style Press Fit
    Housing Material LCP
  • Contact Material Brass
  • Pitch 0.75
  • Housing Color Black
    Data Rates 12Gpbs
Product Drawing

G1213-01

SAS 29p

SAS 29 pin, 15u"&30u"
High Speed Support: SATA 3.0(6Gb/s) & SAS
3.0(12Gb/s)

  • Orientation Vertical
  • PCB Mounting Style Hybrid
  • Housing Material LCP
  • Contact Material Brass
  • Pitch 1.27
  • Housing Color Black
    Data Rates 6Gpbs
  • Size H=14.15mm
Product Drawing

G1213-03

SAS 29p

SAS 29 pin, 15u" & 30u"
High Speed Support: SATA 3.0(6Gb/s)&SAS 3.0(12Gb/s)

  • Orientation Vertical
  • PCB Mounting Style Through Hole
    Housing Material LCP
  • Contact Material Brass
  • Pitch 1.27
  • Housing Color Black
    Data Rates 6Gpbs
  • Size H=8.15mm
Product Drawing

G1213-60

PCIe SAS

PCIe SAS 68 pin, 15u" & 30u"   (SFF 8639)
High Speed Support: SATA 3.0(6Gb/s)&SAS 3.0(12Gb/s)

  • Orientation Vertical
  • PCB Mounting Style SMT
    Housing Material LCP
  • Contact Material Brass
  • Pitch 1.27
  • Housing Color Black
    Data Rates 12Gpbs
  • Size H=8.15mm
Product Drawing

G1213-61

PCIe SAS

PCIe SAS 68 pin, 15u" & 30u" (SFF 8639)
High Speed Support: SATA 3.0(6Gb/s)&SAS 3.0(12Gb/s)

  • Orientation Right Angle
  • PCB Mounting Style SMT
    Housing Material LCP
  • Contact Material Brass
  • Pitch 1.27
  • Housing Color Black
    Data Rates 12Gpbs
Product Drawing

G1213-62

PCIe SAS

PCIe SAS 68 pin, 15u" & 30u"   (SFF 8639)
High Speed Support: SATA 3.0(6Gb/s)&SAS 3.0(12Gb/s)

  • Orientation Right Angle
  • PCB Mounting Style SMT
    Housing Material LCP
  • Contact Material Brass
  • Pitch 1.27
  • Housing Color Black
    Data Rates 12Gpbs
    Size H=4.75mm
Product Drawing

G1213-64

PCIe SAS

PCIe SAS 68 pin, 15u" & 30u"   (SFF 8639)
High Speed Support: SATA 3.0(6Gb/s)&SAS 3.0(12Gb/s)

  • Orientation Vertical
  • PCB Mounting Style SMT
    Housing Material LCP
  • Contact Material Brass
  • Pitch 1.27
  • Housing Color Black
    Data Rates 12Gpbs
  • Size H=8.15mm
Product Drawing

G1213-05

SAS 29p

SAS 29 pin, 15u" & 30u"

  • Orientation Right Angle
  • PCB Mounting Style Through Hole


G1213-04

SAS 29p

SAS 29 pin, 15u" & 30u"

  • Orientation Right Angle
  • PCB Mounting Style Through Hole
Product Drawing

G1215-01

Oculink

Oculink 4x Vertical  15u" & 30u"   (SFF 8611)
High Speed Support: SAS 4.0(24Gb/s)
High Speed Support: PCIe 4.0(16GT/s)

  • Orientation Vertical
  • PCB Mounting Style SMT
    Housing Material LCP
  • Contact Material Brass
  • Pitch 0.5
  • Housing Color Black
    Data Rates 24Gpbs
Product Drawing

G1213-90

Oculink

Oculink 8x Vertical  15u" & 30u"   (SFF 8611)
High Speed Support: SAS 4.0(24Gb/s)
High Speed Support: PCIe 4.0(16GT/s)

  • Orientation Vertical
  • PCB Mounting Style SMT
    Housing Material LCP
  • Contact Material Brass
  • Pitch 0.5
  • Housing Color Black
    Data Rates 24Gpbs
Product Drawing
